A great turnout and a hive of activity for our "Antenna Day"
The club chose a simple 1:49 unun design that uses a common toroid from a local retailer.
Several members constructed Ununs suitable for matching an end fed antenna. Two 3D printed mounting frames were provided.
The use of NanoVNA-Saver was demonstrated drawing a plot of the VSWR of a small indoor end fed cut for 20m. Given that it was hung from pictures around the walls it worked fairly well. Here's a proper plot...
